Product name
|
Industrial resistance meter
|
|
Model
|
HE-480R
|
|
Measurement method
|
Electrode type (2-electrode method)
|
|
Cell constant
|
0.01 /cm
|
|
Temperature sensor
specifications
|
Platinum resistance 1000 Ω / 0 °C
|
|
Measuring range
|
Measurement unit
|
kΩ·m
|
0 to 2.00
|
0 to 20.0
|
0 to 200.0
|
0 to 1000 *
|
|
MΩ·cm
|
0 to 0.200
|
0 to 2.00
|
0 to 20.00
|
0 to 100.0 *
|
|
*: Measurable without temperature compensation
|
|
Temperature: 0 °C to 100 °C (Select your desired decimal point from 0, 1, and 2 digits.)
|
|
Repeatability Within
|
±0.5% of the full scale (in equivalent input)
|
|
Linearity Within
|
±0.5% of the full scale (in equivalent input)
|
|
Transmission
output
|
4 mA to 20 mA DC: input / output isolated type
Maximum load resistance: 900 Ω
Transmission output range: Freely selectable within the measurement range
|
|
Contact output
|
Outputs: 2 points
Alarm contact output (R1 and R2)
Contact type: relay contact, SPDT (1c)
Contact rating: 240 V AC, 3 A and 30 V DC, 3 A (resistance load)
Contact function: selectable from upper / lower limit operation (ON / OFF control), alarm, and maintenance.
|
|
Calibration function
|
Specific resistance
Temperature
|
|
Transmission
output hold feature
|
- Previous value hold
- Optional value hold
- Continuous
Selectable from the above (However, only the previous value hold is available in the maintenance Mode.)
|
|
Self-diagnosis
function
|
- Sensor diagnosis
- Out of the measurement range
- A/D converter scale over
- Converter error
|
|
Temperature
compensation
|
- Based on the temperature characteristics of extra deionized water (reference temperature: 25 °C)
- Based on the reference temperature and user-defined temperature coefficient (reference temperature: 5 °C to 95 °C)
- No temperature compensation
|
|
Temperature - compensated range
|
0 °C to 100 °C
|
|
Extra deionized water specific resistance selection
|
Measurement unit
|
kΩ·m
|
182.3 (standard), 181.8, 182.4
|
Select from options shown on the left.
|
|
MΩ·cm
|
18.23 (standard), 18.18, 18.24
|
|
Clipping function
|
When the measured value is above the upper limit of the measurement range derived from the specified specific resistance, the specified resistance is used as the measured value.
|
|
Power supply
|
Rated voltage 100 V to 240 V AC, 50/60 Hz, 10 VA (max.)
|
|
Structure
|
Indoor-use panel installation type
Panel: IP65 dust and water proof structure
|
|
Protective structure
|
Panel: IP65 (IEC60529, JIS C0920)
|
|
Conforming standards
|
CE Marking
FCC Rule
|
|
External
dimensions
|
48 (W) mm x 96 (H) mm x 115 (D) mm
Case depth: approx. 105 mm (when panel-mounted)
|
|
Mass
|
Approx. 400 g
|
|
Compatible
sensors
|
ERF-series specific resistance sensor, cell constant 1.0 /m (0.01 /cm)
|
